V6 PLUS - The Professional Underwater Solution

Breaking Boundaries - More powerful in functions and simple in operation, FIFISH PRO V6 Plus creates a new way of industry underwater operations

FIFISH PRO V6 PLUS is a professional ROV and has been designed specifically for marine engineering and underwater operations and can reach a depth of 150M.  V6 PLUS is equipped with Q-Motor thruster system and sonar array to perform the Collision Avoidance System and Fixing Distance Scanning functions. The FIFISH PRO V6 PLUS brings simplicity and reliability for professional underwater tasks such as ships hull, bridge structures, reservoir, offshore infrastructure inspections etc
  • 200m Cable
  • Up to 8hr battery life
  • AR Laser Scaler
  • Maximum Speed 3 knots
  • 128mb SD card supplied
  • 4K UHD footage
  • 6000 lumen lights
  • Distance & Altitude Lock
  • Smart Collision Avoidance
  • VR Head tracking system
  • All inclusive smart App
  • Optional Accessories
  • 200m Cable
  • Up to 8hr battery life
  • AR Laser Scaler
  • Maximum Speed 3 knots
  • 128mb SD card supplied
  • 4K UHD footage
  • 6000 lumen lights
  • Distance & Altitude Lock
  • Smart Collision Avoidance
  • VR Head tracking system
  • All inclusive smart App
  • Optional Accessories

True 360° Omni Directional Movement, Free As You Go
FIFISH PRO V6 PLUS has 6 degrees of freedom. Free like a fish, V6 Plus moves in all directions: 360° rotation, lateral and tilt. When moving in any direction, the Posture lock can ensure the angle of the drone.

FIFISH PRO V6 PLUS has 6 degrees of freedom. Free like a fish, V6 Plus moves in all directions: 360° rotation, lateral and tilt. When moving in any direction, the Posture lock can ensure the angle of the drone.

The Q-IF (QYSEA Interface)
The Q-IF (QYSEA Interface) enables V6 PLUS to attach a variety of optional accessories for various applications and multiple tasks. The most popular accessory is the Robotic arm as this enables the V6 PLUS to perform underwater retrieval as the robotic arm can grab objects and features a clamp lock function. With a clamping and towing force of 100N (around 10kg) the full functioning robotic arm can drag, drop, tow and salvage underwater objects. Water sampler, water quality detector, Qysea camera and a special aluminium alloy hook are also available.

6000 Lumen Lights
Featuring 2 x 3000 Lumen LED headlights with different levels of brightness the V6 PLUS can also be used in low visibility or at night.

Removable SD Card
Quickly store and transfer data with the supplied 128mb SD card. The FIFISH PRO V6 PLUS can support up to 512mb SD card.

The Q-IF (QYSEA Interface)
The Q-IF (QYSEA Interface) enables V6 PLUS to attach a variety of optional accessories for various applications and multiple tasks. The most popular accessory is the Robotic arm as this enables the V6 PLUS to perform underwater retrieval as the robotic arm can grab objects and features a clamp lock function. With a clamping and towing force of 100N (around 10kg) the full functioning robotic arm can drag, drop, tow and salvage underwater objects. Water sampler, water quality detector, Qysea camera and a special aluminium alloy hook are also available.

6000 Lumen Lights
Featuring 2 x 3000 Lumen LED headlights with different levels of brightness the V6 PLUS can also be used in low visibility or at night.

Removable SD Card
Quickly store and transfer data with the supplied 128mb SD card. The FIFISH PRO V6 PLUS can support up to 512mb SD card.

FIFISH PRO V6 PLUS SPECIFICATIONS

ROV

Dimensions:           383mm x 331mm x 158mm
Weight:                    5kg
Thrusters:               6 Thrusters (FIFISH Q-Motor Technology)
Manoeuvrability:    6 Degrees of Freedom
                                 Movement: left & right, up & down, forward & backward
                                 Rotation: 360° pitches, 360° rolls, 360° yaws
Posture LockTM:     Lock the ± 0.1° pitch or roll angle, in any direction
Hovering:                Keep the ROV suspending in ± 1cm
Speed:                     Maximum 3 knots
Depth Rating:         150m (492ft)
Temperature Range: -10°C to 60°C (14°F to 140°F)
Max Dive Time:       Up to 4 – 8 hours (depending on usage scenario)
Battery:                    Rated Capacity: 14,400mAH/156Wh
                                  1 hour quick charge
                                  Charge Voltage: 12.6 V
                                  Li-ion Panasonic 21700

LIGHTS

Brightness:            6000 Lumen LED
CCT:                         5500 K (Correlated Colour Temperature)
Beam Angle:           120°
Levels:                    3 x Brightness Levels

CHARGER

ROV:                        Input: 100-240, 50/60Hz, 1.3 A Max
                                Output: 12.6V=10A
RC:                          Input 100-240, 50/60Hz, 0.5 A Max
                                Output: 5V = 3A

DISTANCE LOCK, ALTITUDE LOCK SONAR SYSTEM

Detection Range:   0.4 – 3m
Precision:                +/- 5cm

TETHER

Length:                    200m standard on spool
Breaking Force:      120 kgf

CAMERA

Sensor:                1/2.3” SONY CMOS
Pixels:                  12M
ISO Range:           100 – 6400 in Auto/Manual
Lens:                     Field of View: 166 °
                               Aperture: f/2.5
                               Minimum Focus Distance: 0.4m
Shutter Speed:     5 -1/5000 Second
Burst Shooting:    1 / 3 / 5 / 7 / 10 Frames
White Balance:     2500K – 8000K
Exposure Comp.: -3.0EV to +3.0EV
Photo Resolution: 4:3: 4000 x 3000
Photo Format:       JPEG, DNG
Video Res:             4K UHD: 25/30 fps
                                1080P FHD: 25/30/50/60/100/120 fps
                                720P HD: 25/30/50/60/100/120/200/240 fps
Video Format:        MPEG4 – AVC/H.264, HEVC/H.265
Stabilisation:          EIS (Electronic Image Stabilisation)
Colour Encoding:  NTSC & PAL
Storage:                 Pluggable 128GB standard, support up to
                                512GB

CONTROLLER

Wireless:                5GHz WiFi,11a,n, ac
Battery Life:           Up to 4 hours
Copy & Download: Format in FAT32 & EXFAT (up to 128GB)

ROBOTIC ARM (optional)

Size:                        140mm
Grip:                        10kgf
Supply Voltage:      9 – 12V
Max Current:          3A

LASER RULER

Laser Tube Type:   Spot laser
Wave Length:         650nm (red)
Scale Length:         12cm

Product specifications & accessories are subject to change without notice
